Vertical vs Horizontal Windlass: One Measurement Decides It
One measurement decides this, and it is not your boat length. Drop a tape into your anchor locker and measure the fall: the vertical drop from under the deck to the top of the piled chain.
16 in (406 mm) or moreVerticalFrom $1,587.45
Motor below deck, only the gypsy on show. Strongest chain grip and the cleanest foredeck. Starts with the Storm VR600.
12 in (300 mm) or moreHorizontalFrom $1,679.20
Everything above deck. Fits shallow lockers, easiest to install and service. Starts with the HR650 Lynx.
No usable lockerDrum winchFrom $1,106.75
No gypsy and no locker feed. The whole rode winds onto the drum, so fall depth stops mattering. Starts with the DW 06.
The measurement that decides it
Fall is the vertical drop from the underside of the gypsy to the top of the chain once it has piled up in the locker. Chain needs somewhere to fall away to. If it does not have that room it stacks into a cone, reaches the gypsy, and the windlass jams.
A vertical windlass wants 16 in (406 mm) of fall. A horizontal needs about 12 in (300 mm), because the gypsy sits above deck and the chain turns through 90 degrees instead of dropping straight down. If you have neither, that is not a failure of measurement. It is the answer, and the answer is a drum winch.
What a vertical windlass is
The motor and gearbox mount below deck. Above deck you see the gypsy, and on the VRC models a capstan drum for warping lines.
The chain wraps roughly 180 degrees around the gypsy before dropping into the locker. That wrap is the whole engineering argument for the format: more contact means more grip, and less chance of the chain slipping under load.
- Stronger chain grip, from the fuller wrap.
- Low, clean foredeck with more usable deck space.
- Takes the rode from a wide range of feed angles, and one unit can serve twin bow rollers.
The costs are real. You need the locker depth, you need room below deck for the motor, and the motor then lives in a damp space where access is awkward. On the Storm VR600, Muir specifies 6.8 in (173 mm) of depth and 9.2 in (233 mm) of width below deck for the motor and gearbox, on top of the fall the chain needs. That width catches people out more often than the depth does. We have tabulated both figures for every model in will it fit.
What a horizontal windlass is
Motor and gearbox sit above deck, so the entire unit is visible and reachable. The chain makes about a 90 degree turn over the gypsy and drops through the chain pipe.
- Works in a shallow locker, which is what saves the job on many boats.
- Simplest installation. You cut for the chain pipe, wiring and mounting bolts, and nothing else.
- Everything is on deck, so servicing is straightforward.
In exchange you give up grip, because that 90 degree wrap holds the chain less firmly. The unit occupies deck space and takes weather and foot traffic. It also has to line up accurately with the bow roller, because the rode must lead straight onto the gypsy rather than at an angle.
Side by side
| Vertical | Horizontal | Drum winch | |
|---|---|---|---|
| Motor position | Below deck | Above deck | Above deck |
| Locker fall needed | 16 in (406 mm) | 12 in (300 mm) | None |
| Chain grip | ~180° wrap, strongest | ~90° wrap, less | No gypsy |
| Deck footprint | Smallest | Largest | Large |
| Bow roller alignment | Wide feed angle, twin rollers possible | Must line up straight | Wide feed angle |
| Installation | Below-deck work required | Mostly above deck | Bolt to the deck |
| Servicing | Motor in a damp locker | All on deck | All on deck |
| Rode type | All chain, or rope and chain | All chain, or rope and chain | Rope with a chain leader |
| Entry model | Storm VR600, $1,587.45 | HR650 Lynx, $1,679.20 | DW 06, $1,106.75 |
Format does not set the price
It is tempting to assume one format costs more. It does not work out that neatly.
At the small end the vertical is cheaper: the Storm VR600 and the HR650 Lynx both work at 271 lb (123 kg), and the vertical costs $91.75 less. In the middle it flips: the HR950 Lynx works slightly harder than the Storm VR850 and costs $175.75 less. At the top it flips back, with the HR1600 Cougar at $674.90 more than the Storm VR1250 for identical pull.
So compare the specific pair you are choosing between, not the formats in general. The pattern does change above 40 ft, where verticals pull ahead on price and stay there: we have priced every model against rated boat length in the windlass cost guide.
What about drum winches
Vertical and horizontal are not the only options, and on a lot of smaller boats they are not the right ones.
A drum winch has no gypsy. The rope and chain rode winds onto the drum, so there is no chain to match, no locker to feed and no fall to measure. On a trailer boat where the locker is a moulded tray, that is not a compromise. It is the only format that actually fits.
The trade-offs: it takes a rope rode with a chain leader rather than all chain, the rode has to spool evenly so it wants a guide roller and some attention early on, and the drum occupies its own space on the bow. The range runs from the DW 06 at $1,106.75 for boats to 23 ft, through the DW 08 at $1,268.25, to the DW 10 at $1,800.25 for boats to 33 ft. If you are weighing the two formats against each other, we have taken them head to head in drum winch vs windlass.
Choosing, in order
Work through it in this sequence and the decision makes itself.
- Measure the fall. Under 12 in and you want a drum winch. Between 12 and 16 in, horizontal. Over 16 in, either format is open to you.
- Check below deck. A vertical needs clear space under the deck for the motor, roughly 6.8 in deep and 9.2 in wide on the 600. Measure the width, not just the depth.
- Look at your bow roller. If it is off centre, or you run twin rollers, a vertical handles the feed angle. A horizontal has to line up straight.
- Then size it. Lewmar’s rule is a windlass rated to at least four times the weight of your anchor, chain and rode combined. On most boats under 40 ft this is not the binding constraint. Locker geometry is.
Mistakes that cost money
- Sizing on boat length instead of ground tackle. Two 35-footers can need different winches if one runs all chain and the other runs rope with a chain leader.
- Choosing the format before measuring the locker. This is the expensive one, because you usually discover it after the deck is cut.
- Mismatching the gypsy to the chain. Size alone is not enough. Metric DIN 766 and US G4 differ in pitch, and a gypsy cut for one will skip on the other.
- Forgetting the cable. Undersized cable drops voltage, the motor works harder to compensate, and it runs hot. Size it to the run length, not to the breaker.
- Using the windlass as a cleat. Once the anchor is set, the load belongs on a chain stopper or a snubber.
Frequently asked questions
Is a vertical windlass better than a horizontal?
Neither is better in the abstract. A vertical grips the chain harder and leaves a cleaner deck, but needs a deeper locker and below-deck space. A horizontal fits shallow lockers and is far easier to install and service. Your anchor locker decides which of those matters.
Which is easier to install?
Horizontal, clearly. The motor and gearbox stay above deck, so you avoid the below-deck work a vertical needs. If you are fitting it yourself rather than paying a yard, that difference is significant.
How do I know which will fit my boat?
Measure the fall in your anchor locker. Under 12 in (300 mm) rules out both gypsy formats. Between 12 and 16 in, horizontal. Over 16 in (406 mm), check you also have room below deck for a vertical’s motor. Every product page carries a downloadable deck template under the Downloads tab.
Can I replace a horizontal windlass with a vertical one?
Sometimes, but check two things first: whether the locker has 16 in (406 mm) of fall, and whether there is clear space below deck for the motor. Going the other way, horizontal to vertical is rarely a problem, since a horizontal asks less of the locker.
Does a vertical really grip better?
Yes, and the reason is geometry rather than marketing. The chain wraps about 180 degrees around a vertical gypsy against roughly 90 degrees on a horizontal. More contact means more friction and less chance of slipping when the load comes on.
What size windlass do I need?
That depends on boat length and how much chain you carry. We have worked both brackets through with verified figures: see best windlass for small boats for boats under 30 ft, and 30 ft and 40 ft boats above that.
Can one windlass serve twin bow rollers?
A vertical can, because it accepts the rode across a wide feed angle. A horizontal generally cannot, since it has to line up straight with a single roller.
